Hellan 6" 150 Brass In-line Flow Type DH Manual Strainer

LOCAL PICK UP ONLY

Hellan 0603DH Manual Strainer

Line Size/Connection: 6" 150 FF
Material: Brass
Type: DH
Two strainers
For marine applications.

"Type DH Hellan Strainers employ two handwheel-equipped rotating screens and rigid scraper bars to remove solids from the surface of the screens when the handwheels are rotated.  A solids-collecting sump is also provided. Cleaning of the Type DH strainer is accomplished by opening a valve on the sump flush connection and rotating the handwheels several times. For best results, the cleaning cycle should be performed when the strainer is under a positive pressure.  An eductor and/or backwash may aid in debris removal in low-pressure applications. Type DH can be installed in vertical up-flow or horizontal flow position (with the drain discharging downward)."

This item is available for local pickup only. Forklift available to load onto your vehicle or carrier.
Shipping is possible, freight charges will apply.  Call for details.

0603DH-HELLAN
